1. The PLC and touch screen control system
2. Automatic one-off manipulator width adjustment
3. The frequency converter control different running speed
4. The Angle of pneumatic components of memory automatically adjust values
5. Self automatic detection, information feedback, etc
6. The central lubrication automatic refueling system
7. The stability of the mechanical CAM transmission technology
8. No bag - machine alarm/downtime
9. No product - machine stop
10. Open a bag of error - not filling - no sealing
11.0 temperature machines alarm/fault - stop
12. The problem of screen display failure - simple ruled out
13. Security door open - the machine stopped
14. Can be set up water cleaning
15. The wide range of packaging, applicable to solid, liquid, paste, powder, granule, pickles, irregular material and other material, only need to choose according to different materials of different measuring filling device
Equipment model | RL6-200A / RL8-200A | |||
Mechanical station | Six / eight stations | |||
Workflow | 1. Bag loading 2. Marking & amp; Open bag 3, cut 4, vibration & amp; Stabbing pressure 5, seal 6, seal output < br / > | |||
1. Bag loading 2, marking 3, & amp; Open bag & nbsp; 4. Blanking 5. Reserved 6. Compaction 7. Sealing 8. Sealing output < br / > | ||||
Bag type | Four side seal, self-supporting bag, zipper bag, handbag, paper bag and other composite bags | |||
Package size |
W:60~200mm L:≤350mm |
|||
Filling range < br / > | 10 g to 1500 g (with bag capacity and material characteristics) | |||
Packaging speed | 10-55 pack / minute (speed depends on product itself and filling weight) | |||
Total power | 380V 2KW | |||
Machine weight | 1200KG | |||
External dimension | 164x145x145cm | |||
Compressed air consumption | 6 m3 / min (compressed air provided by users) |
