1, the fully automatic rotary type vacuum packing machine (filling system and vacuum system, respectively);
2, easy to operate: adopting PLC touch screen control, operating system interface, convenient operation and intuitive;
3, convenient adjustment, realize fully automated, just from the man-machine interface, enter the required parameters of packaging machine can automatically adjust to the required order part;
4, high degree of automation: meet the requirements of automatic vacuum, realize unmanned in the process of weighing, packaging, failure automatic alarm;
5, perfect prevention system, intelligent test whether to open the bag and the bag opening is complete, in the case of improper feeding material heat sealing, do not waste bags and logistics, cost savings;
6, the equipment conform to the hygiene standards of food processing machinery, equipment and material contact part adopts 304 stainless steel or other to meet the requirements of food hygiene materials processing, to ensure food hygiene and safety, comply with the GMP standard;
7, easy to clean, clean vacuum chamber can be.
| Equipment model | RL - GD - ZK130 | RL - GD - ZK160 | RL - GD - ZK200 |
| Drive way | Frequency conversion motor drive/servo drive | ||
| Packaging materials | Aluminum foil bag, the compound flat bags, PE bags, cooking bags | ||
| Packaging specifications | W: 50-130 - mm L: 200 mm or less | W: 80-160 - mm L, 210 mm or less | W: 130-200 - mm & have spent L: 300 mm or less < br |
| Filling range < br / > | 10 g ~ 500 g (features) | ||
| Packing speed | 30 ~ 65 bags/min (speed is determined by the product itself and the filling weight) < br / > | ||
| Weighing accuracy | Deviation of plus or minus 1% or less (features) | ||
| The host weight | 1600 kg | ||
| The host power | 4 kw (excluding vacuum pump) | ||
| Drive power supply | 380 v three-phase five line of 50 hz | ||
| Exterior size < br / > | 2200 x1600x2300mm (not including hoist) | 2420 * 1700 * 1800 (L * W * H) | 2420 * 1700 * 1800 (L * W * H) |
| Compressed air consumption < br / > | Acuity 0.6 m3 / min (air supplied by the user) | ||
| Cooling water < br / > | Cooling water: 15-20 ° C, 3 litres/minute | ||
| Control the power | DC24V | ||
