1. This machine USES the stable CAM mechanical transmission technology, make the equipment operation is stable, low fault rate, low energy consumption. At the same time, the machine USES high-end circuit structure, man-machine interface (such as PLC + HMI) technology, electromechanical integration, easy operation and simple. ?
2. Only on the large color touchscreen, corresponding input device can automatically adjust the packaging size, packaging speed, sealing temperature, etc.
3. The process of production equipment with automatic test system, and automatically adjust elements Angle parameters, the system will alarm and show the cause of the alarm, the touch screen. Technicians can troubleshoot directly. To achieve ??no bag or bags no success - no - no sealing??, packing high yield.
4. The products add the door stop, exhaust, compaction, automatic card, abnormal discharge, automatic filling details such as the function of lubricating oil, packaging process without manual operation, effectively improve the production efficiency, save the labor cost and management cost, greatly reduce the cost and improve production efficiency. ?
5. Packaging and material contact parts adopt stainless steel or other conform to the requirements of the food hygiene materials processing, to ensure that the food hygiene and safety, food hygiene standards.
6. Adopt PLC control system in Germany. Adopts stepless frequency converter, main motor, PLC, inverter, sensor, relay, contactor, pneumatic components for the international brand;
7. Packaging machine control measure according to release material, no waste of material.
8. The equipment configure security door, protect door use transparent organic glass.
9. The unique number bag/a number of special programs.
10. Adopting chute, insulation material can avoid congestion.
11. The weighing type material detection switch, can avoid the accumulation of material in the center of the main vibration.
12. Special bi-model main vibration plate rotating with a cleaning rod, through positive and negative rotation assigned to each wire vibration plate.
13. Built-in weighing and the number of bags/number two modes available, implement your more requirements.
Model |
RL200-S |
Composition of production line | To bag packing machine, bag scale, material hoist, working platform |
Bag type | Self supporting bag, flat bag (three side seal, four side seal, tote bag, zipper bag) |
Bag size |
Type 200: (W: 10-23cm; H:≤35cm) ; Type 250: (15-25cm; L:≤35cm); Type 300 (W: 20-32 cm. H; ≤45cm) |
Packaging speed |
25-40bag / min (the specific speed is determined by the material itself and the filling weight) |
Using power | Three phase 380V, 50 / 60Hz |
Packaging speed | 20-45 bags / min |
Total power | 6.5KW |
Gross weight of machine | 1.8 T |
Floor size | five thousand and five hundred × two thousand and five hundred × 4000mm |
