1. This machine adopts the most stable CAM mechanical transmission technology, make the equipment operation is stable, low fault rate, low energy consumption. At the same time, the machine USES high-end circuit structure, man-machine interface (PLC + HMI), and other advanced technology, electromechanical integration, easy operation and simple.
2. Using the latest German PLC control system. Adopts stepless frequency converter, main motor, PLC, inverter, sensor, relay, contactor, pneumatic components are all international famous brand.
3. Only in the large color touch screen, corresponding input device can automatically adjust the packing weight, packing speed, the sealing temperature, etc.
4. The process of production equipment with automatic test system, and automatically adjust elements Angle parameters, the system will alarm and show the cause of the alarm, the touch screen. Technicians can troubleshoot directly. To achieve ??no bag or bags no success - no - no sealing??, packing high yield.
5. Automatic injection products add to open the door stop, details such as the function of lubricating oil, packaging process without manual operation, effectively improve the production efficiency, save the labor cost and management cost, greatly reduce the cost and improve production efficiency. ?
6. Bags and material contact parts are imported engineering plastic bearings and stainless steel parts, without refueling, reduce pollution and corrosion resistance of the material.
Equipment have waterproof function, the production has been completed, equipment can be directly flush
Model |
RL200-Z |
Bag type | Flat bag (three side seal, four side seal, self-supporting bag) |
Bag size | W:65-200mm L:100-350mm |
Fill range |
15-500g |
Quantify precision | The average precision is 1.5g |
Packaging speed | 40-55 bags / min (the speed is determined by the material itself and the filling weight) |
hopper capacity | 1300ml |
Voltage | 380V three phase, 50Hz |
power | 5kw |
Dimensions | 2100x2500x2300mm |
compressed air | 500N liter / min, 6kg / cm3 (provided by the user) |
