1. USES Germany Siemens PLC control, touch screen man-machine interface control system, easy to operate.
2. The frequency control of motor speed, this machine USES frequency conversion speed regulating device, can adjust at will speed within the specified scope.
3. Automatic detection function, such as not open bags or bags are not complete, not charging, no heat sealing, bag can use again, do not waste material, saving the cost of production.
4. Safety device, when the work pressure is not normal or heating tube failure, will alarm prompt.
5. Random with organic glass door, when the door is open the machine stop running immediately, protect the operators.
6. Part adopts imported engineering plastic bearings without refueling, reduce the pollution of material;
7. Oil-free vacuum pump is adopted to avoid pollution of production environment.
8. Conform to the hygiene standards of food processing industry, machine parts in contact with the material or packing bag is made of stainless steel or other to meet the requirements of food hygiene materials processing, to ensure the health and safety of food.
9. With liquid mixing device, prevent precipitation, micro particle material with liquid level control device.
Servo control quantitative production, weight can be set on the touch screen, convenient and simple.
Model |
RL200-Y |
Packaging type | Constant temperature heat seal |
Bag size |
Type 200: (W: 10-23cm; H:≤35cm) Type 250: (15-25cm; L:≤35cm); Type 300 (W: 20-32 cm. H; ≤45cm) |
Packing weight | ≤1000g |
Packaging speed |
20-50bag / min (the specific speed is determined by the material itself and the filling weight)
|
Packaging accuracy | ≤ ± 1% |
Packaging speed | 20-45 bags / min |
Using power | Three phase 380V, 50 / 60Hz |
power | 3kw |
compressed air | 0.6m3/min (provided by user) |
The overall dimension |
two thousand two hundred and fifty × one thousand and five hundred × 1500mm |
Workflow | Six working positions: 1. Bag feeding 2. Coding 3. Bag opening detection 4. Filling 5. Heat sealing 6. Heat sealing 2. Shaping output |
Eight stations: 1. Bag feeding 2. Coding 3. Bag opening 4. Detection 5. Filling 6. Second filling 7. Heat sealing 8. Heat sealing 2. Shaping output |
