1, the fully automatic rotary type vacuum packing machine (filling system and vacuum system, respectively);
2, easy to operate: adopting PLC touch screen control, operating system interface, convenient operation and intuitive;
3, convenient adjustment, realize fully automated, just from the man-machine interface, enter the required parameters of packaging machine can automatically adjust to the required order part;
4, high degree of automation: meet the requirements of automatic vacuum, realize unmanned in the process of weighing, packaging, failure automatic alarm;
5, perfect prevention system, intelligent test whether to open the bag and the bag opening is complete, in the case of improper feeding material heat sealing, do not waste bags and logistics, cost savings;
6, the equipment conform to the hygiene standards of food processing machinery, equipment and material contact part adopts 304 stainless steel or other to meet the requirements of food hygiene materials processing, to ensure food hygiene and safety, comply with the GMP standard;
7, easy to clean, clean vacuum chamber can be.
| Model |
RL-GD-ZK160L |
RL-GD-ZK200L |
| Bag material | Composite film PP / PE | |
| Bag type | Flat bag, cooking bag, aluminum foil bag, PE bag and other composite bags | |
| Bag size | W:80-160mm L：80-210mm | W:130-200mm L:≤300mm |
| Fill range |
10-500g |
|
| accuracy | ≤ ± 1% | |
| Packaging speed | 30-60 bags / min (the speed is determined by the material itself and the filling weight) | |
| Voltage | 380V three phase, 50Hz | |
| power | 8kw | |
| compressed air | 6 m3 / min (provided by users) | |
| Cold cut water | Cold cut water: 15-20 ° C. 3 L / min | |
