| Model | RL-GD8-ZK10-200 | RL-GD8-ZK10-240 |
|
Mechanical |
8 stations +10 vacuum chamber |
8 stations +10 vacuum chamber |
|
Equipment material |
304 stainless steel (part in contact with food) |
|
|
Packagin materials |
Packaging materials Plane bag, four side sealing bag, aluminum foil bag, cooking bag.composite paper bag, etc |
|
|
Bag size |
Width: 120-200mm length: 150-300mm |
Width: 120-240mm length: 80-320mm |
|
Packing speed |
10-50 bales/min(the speed depends on the product itself and the filling weight) |
10-40 bales/min(the speed depends on the product itself and the filling weight) |
|
The sealing way |
Instant heating sealing, water cooling mode, to ensure that the sealing is beautiful |
|
|
For the material |
Hotpot bottom material, bean products, meat products, egg products, pickles, leisure food and other packaging materials |
|
|
The working process |
Bag feeding: Bag loading→ Coding(optional）→ Bag opening→ Filling1→ Filling2→Blowing dust at the mouth of bag→ Switching vacuum cavity Vacuum: after filling and transferring to the vacuum turntable → decompression and vacuumizing → continuous vacuumizing + sealing → pressure relief → output |
|
|
The total power |
10KW | |
|
Machine weight |
2800KG | 3000KG |
|
Overall dimension |
2450mm X 1700mm X 1700mm(LXWXH) |
2650mm X 1700mm X 1700mm(LXWXH) |
|
Compressed air consumption |
23/5000 >0.6 cube/ min(Compressed air is provided by users themselves |
|
