| Model |
RL-GD10-ZK12-200P |
| Drive way |
Mechanical transmission (whole machine mode of convex gear lever) |
|
Measurement methods |
Manual feeding, automatic screw metering, automatic bowl feeding, combined scale, etc. (adaptable) |
|
Equipment material |
304 stainless steel (part in contact with food) |
|
Packagin materials |
Aluminum foil bag, paper bag (surface covered with paper), nylon bag, etc |
|
Bag size |
Width: 100-200mm length: 150-300mm |
|
Packing speed |
20-45 bales/min(the speed depends on the product itself and the filling weight) |
|
The sealing way |
Instant heating sealing, water cooling mode, to ensure that the sealing is beautiful |
| Dirve power supply |
Three phase 380V 50Hz (non international three phase 380V 60Hz) |
|
The working process |
Bag feeding: Bag loading→ Coding(optional）→ Bag opening→ Filling1→ Filling2→Blowing dust at the mouth of bag→ Switching vacuum cavity Vacuum: after filling and transferring to the vacuum turntable → decompression and vacuumizing → continuous vacuumizing + sealing → pressure relief → output |
|
The total power |
aoubt 9KW |
|
Machine weight |
300KG |
|
Overall dimension |
2400mm X 2100mm X 1600mm(LXWXH) |
|
Compressed air consumption |
23/5000 >0.8 cube/ min(Compressed air is provided by users themselves |
