| Model |
RLGD10-ZK12-130 |
|
Mechanical |
10 stations +12 vacuum chamber |
|
Equipment material |
304 stainless steel (part in contact with food) |
|
Packagin materials |
Packaging materials Plane bag, four side sealing bag, aluminum foil bag, cooking bag.composite paper bag, etc |
|
Bag size |
Width: 55-130mm length: 80-190mm |
|
Design speed |
90/ package |
|
Packing speed |
70-90 bales/min(the speed depends on the product itself and the filling weight) |
|
The sealing way |
Instant heating sealing, water cooling mode, to ensure that the sealing is beautiful |
|
For the material |
Soybean products, meat products, egg products, pickles,marinated food and other leisure food |
|
The working process |
Bag feeding: Bag loading→ Coding(optional）→ Bag opening→ Filling1→ Filling2→Blowing dust at the mouth of bag→ Switching vacuum cavity Vacuum: after filling and transferring to the vacuum turntable → decompression and vacuumizing → continuous vacuumizing + sealing → pressure relief → output |
|
The total power |
10KW |
|
Machine weight |
3500KG |
|
Overall dimension |
2830mm X 1685mm X 1600mm(LXWXH) |
|
Compressed air consumption |
23/5000 >0.6 cube/ min(Compressed air is provided by users themselves |
